The 11814E large capacity electric fryers have 60-lb. (30 liter) frypot oil capacity with an 18” x 14” x 4-1/4” (45.7 x 35.6 x 10.8 cm) cooking area. The ability to cook three baskets of food in an 18” x 14” x 4-1/4” cooking area allows for footprint, oil use and energy use reductions over standard 50-lb fryers. Two 11814E fryers can do the work of three standard fryers and two 11814E fryers combined with an RE17 fryer allows three fryers to do the work of four standard fryers. The savings add up quickly using 15-20% less oil, upwards of 33% less energy, and 10-15% less space.
Frymaster’s proprietary self-standing, swing-up, flat-bar, low-watt density, long-life heating elements and controls ensure industry-leading energy efficiency.
The robust RTD, 1° Compensating temperature probe, mounted on the elements, ensures precise temperature readings. The thermostat system minimizes temperature overshoot maximizing oil life. It also compensates for variations in cooking loads, consistently producing high-quality food.
The SMART4U Lane controller has programmable cook buttons and features that make it easy to produce consistent, great-tasting food. The Analog*, Digital, CM3.5, and SMART4U® 3000 controller options are also available.
The bottom of the frypots are sloped toward the front and are equipped with a large drain line so crew members can quickly flush out sediment and remove old oil.
The built-in filtration models make it easy to preserve oil life and maintain food quality. The built-in filter utilizes an 8 GPM (30 LPM pump and is equipped with a 3” (7.61 cm) drain line, making filtering fast, safe and easy. The “built-in” feature puts filtration within the fryer battery where it’s most convenient to use.
18" x 14" x 4-1/4" (45.7 x 35.6 x 10.8 cm) frying area per 60-lb. electric frypot 11814E/RE17/11814E (with filter) two 18" x 14" x 4-1/4" (45.7 x 35.6 x 10.8 cm) 60-lb. electric frypots and one 14" x 14" x 3-1/2" (35.6 x 35.6 x 8.9 cm) electric frypot
11814E & 11814EF = 17 kw 21814EF, 31814EF, 41814EF = 17 kw per frypot RE17 = 17 kw
SMART4U® Lane controller has programmable cook buttons and features that make it easy to produce consistent, great-tasting food.
Proprietary, self-standing, swing-up, flat-bar low-watt density long-life heating elements.
Robust, RTD, 1° compensating temperature probe.
Stainless steel frypot, front and cabinet sides
Sturdy, stainless steel, over-the-flue basket hangers.
Three twin -- 11814E & 11814EF models Six twin -- 21814EF model Nine twin -- 31814EF model Twelve twin -- 41814EF model Eight twin -- 11814E/RE17/11814E model
1814EF, 21814EF, 31814EF, 41814EF and 11814E/RE/11814E models come standard with built-in filtration
Casters on Filter Models
21814EF, 31814EF, 41814EF and 11814E/RE/11814E models come standard with casters
