Frymaster’s proprietary self-standing, swing-up elements and precise controls ensure industry-leading energy efficiency with ASTM ratings greater than 83%, far exceeding ENERGY STAR® qualification standards and qualify these fryers for energy-saving rebates. The thermostat, mounted on the elements, ensures precise temperature readings. The thermostat system minimizes temperature overshoot maximizing oil life. The large cold zone and forward sloping bottom help collect and remove sediment from the frypot to safeguard oil quality and support routine cleaning. A rear flush feature moves sediment to the front drain valve for easy and thorough removal. These models will accommodate additional accessories including CM3.5 controller (standard on TC models) and automatic basket lifts. The fryer cabinet can include an additional spreader cabinet with an optional heat lamp and holding station. The TC model electric fryers have advanced electronic switching devices which pulse the amount of energy required to the electric elements in much smaller increments than traditional on/off electrical contactors or gas controls. The result: greater reliability and more precise temperature control. These models also have an insulated frypot which can reduce standby energy consumption by an additional 10%, and they come standard with the CM3.5 controller which ensures pinpoint accuracy of oil temperature and adjusts cooking time for consistent high-quality production.
50-lb (25 liter) oil capacity
Deep cold zone with 1-1/4" IPS ball-type drain valve
Stainless steel frypot, door and cabinet
CM3.5 controller
Open frypot (full or split), easy to clean
Drain safety switch on all Frymaster filter system fryers
Proprietary, self-standing, swing-up flat-bar, low-watt density, long-life heating elements with power interruption if elements are raised
Designed on rails to clear floormats for easy cleaning Sloped pan leaves minimal residue oil behind after filtering
Full frypot = 14" x 15-1/2" (35.6 x 39.4 cm) Split frypot = 6-3/4" x 15-1/2" (17.2 x 39.4 cm)
14kw
Robust, RTD 1° compensating temperature probe
