• Welded tank with an extra smooth peened finish ensures easy cleaning.
• Long-lasting, high-temperature alloy stainless steel heat baffles are mounted in the heat exchanger tubes to provide maximum heating and combustion efficiency.
• Standing pilot light design provides a ready flame when heat is required.
• Cabinet front and door are constructed of stainless steel with galvanized sides and back.

Operations

• Standing pilot and thermostat maintain temperature automatically at the selected temperature (between 93°C and 190°C).
• Cooks 28.6Kg of fries per hour.
• Front 3.2cm NPT drain for quick draining.

Control

• Thermostat maintains selected temperature automatically between 93°C and 190°C.
• Integrated gas control valve acts as a manual and pilot valve, automatic pilot valve, gas filter, pressure regulator (for gas pressure higher then /2 psi needs external regulator), and automatic main valve.
• Gas control valve prevents gas flow to the main burner until pilot is established and shuts off all gas flow automatically if the pilot flame goes out.
• Temperature limit switch safely shuts off all gas flow if the fryer temperature exceeds the upper limit.

Standard acessories

• Built-in integrated flue deflector.
• Galvanized sides and back.
• Tank - mild steel with stainless front.
• Cabinet-stainless steel front, door.
• Two nickel plated oblong, wire mesh baskets.
• Adjustable leg.
• One drain extension.
• One nickel-plated tube rack.
• One drain line clean-out rod.
• Removable basket hanger for easy cleaning.
